Model #: BMVL-30

BMVL-30 - Ballymore Mobile 1 Person Vertical - 30' Lift, 300 Lb. Capacity

$14,888.00
View My Quotes

Shipping Details

Purchases are for commercial businesses only. We will not ship to personal residence.

Shipping Information

General Shipping Guidelines

Purchases are for commercial businesses only. Will not ship to personal residence.

Only carriers that accept freight from both Coatesville and Pittsburgh are ABF (preferred), Ceva (customer must have an account), Ward (customer must have an account), and Estes (with limitations).

Logistics companies must confirm their use of one of these carriers before orders are accepted.

Shipments to California or Canada automatically trigger CAL-Osha requirements if they are five or more steps. Commercial invoices are mandatory for shipments to Canada, along with broker information.

  • No flatbeds, refrigerated truck or pickup trucks
  • Dry Van only
  • Wood floors only
  • Fully enclosed freight trucks only
  • Swing doors required for larger items that ship assembled/ all welded

Specific quantities may change LTL shipments to truckload shipments based on item dimensions and quantity (e.g., six ML154021P would be a dedicated truck shipment, while six 063214P would be two pallets at 96x40x60 each).

Learn More Opens in a new tab.

This push around lift is designed for one person and reaches a maximum platform height of 30'. The working height is approximately 35' which makes it ideal for light and ceiling maintenance. The BVML-30 climbs and descends smoothly and quietly. The lift is dc powered with an easy to use control box. Included as an added safety feature are outrigger interlock display lights which indicate when all four outriggers are down and in place. The lift will not ascend unless all four outriggers are firmly in place. The BMVL-30 compacts for easy storage and rolls for passage through doorways. Lift is also equipped with tilt and lift for easy loading. Outrigger footprint: 64"x74". Stows away at 78" for doorway access.
  • Manually Propelled Maintenance Lift
  • Working Heights To 35"
  • Compact Design For Easy Storage
  • 29x56 Base Allows Lift To Roll Through Standard Doorways
  • Easy To Use Outriggers Extend From Base To Provide Excellent Stability
  • 12 Volt Dc Power (raise And Lower)
  • Complies With Applicable OSHA & ANSI Standards
  • Designed For Indoor Use
  • Assembled L X W X H: 29x56x78
  • Base W x L: 29" X 56"
  • Category: Lifts
  • Color: Blue
  • Eligible for UPS: No
  • Entrance Chain: No
  • Final Weight: 950
  • Freight Class: 125
  • Freight Class #2: n/a
  • Lockstep Type: N/A
  • Overall Height Fully Lowered: 78"
  • Overall Packaging Height: 78
  • Overall Packaging Length: 82
  • Overall Packaging Width: 32
  • Platform Dimensions: 24" X 27"
  • Platform Max: 30'
  • Platform Min: 10"
  • Power - Batteries: 12V
  • Pushable / Drivable: Pushable
  • Recommended Freight Method: LTL
  • Shipping Dims. LxWxH: 82x32x78
  • Shipping Weight: 950
  • Skid Dims: 82x32x5
  • Skid Dims #2: n/a
  • Skid Height: 5
  • Skid Height #2: n/a
  • Skid Length: 82
  • Skid Length #2: n/a
  • Skid Weight: 40
  • Skid Weight #2: n/a
  • Skid Width: 32
  • Skid Width #2: n/a
  • Sub: 2
  • Subcategory/Type: Vertical Mast Lifts
  • Video URL: https://vimeo.com/Ballymore/verticalmastlift
  • Weight Capacity: 300
  • Working Height: 35'
