  • G-Series Light Duty Lift Table 3K Capacity 48x48 Hand Controls
Pinch To Zoom
Model #: BM-GSLD-3K-40R-4848-H

G-Series Light Duty Lift Table 3K Capacity 48x48 Hand Controls

Shipping Details

Purchases are for commercial businesses only. We will not ship to personal residence.

Shipping Information

General Shipping Guidelines

Purchases are for commercial businesses only. Will not ship to personal residence.

Only carriers that accept freight from both Coatesville and Pittsburgh are ABF (preferred), Ceva (customer must have an account), Ward (customer must have an account), and Estes (with limitations).

Logistics companies must confirm their use of one of these carriers before orders are accepted.

Shipments to California or Canada automatically trigger CAL-Osha requirements if they are five or more steps. Commercial invoices are mandatory for shipments to Canada, along with broker information.

  • No flatbeds, refrigerated truck or pickup trucks
  • Dry Van only
  • Wood floors only
  • Fully enclosed freight trucks only
  • Swing doors required for larger items that ship assembled/ all welded

Specific quantities may change LTL shipments to truckload shipments based on item dimensions and quantity (e.g., six ML154021P would be a dedicated truck shipment, while six 063214P would be two pallets at 96x40x60 each).

Learn More Opens in a new tab.

The G-Series lift tables have been designed as an economical solution for light duty applications. Available with 2,000 & 3,000 lb. Capacities, the G-Series table can improve productivity and reduce injuries by placing loads at an ergonomic work height. The heavy duty 1. 7 HP lift motor allows up to 12 full lifts per hour on average, with a competitive lift speed and runs on a 115 volt input 15 amp circuit. Available in 4 models, the G-Series has the right table for many applications. The G-Series tables are stock items and can usually ship in 24 hours. The 3G-series lift tables features a 2 lift cylinder for increased capacity and has the same standard features as the 2g models.
  • Upper Platform Full Perimeter Safety prevents descent upon obstruction
  • Electric circuit reset button in case safety perimeter bar is activated
  • Upper limit switch shuts motor off at full height extension reducing wear
  • Single acting lift cylinder with flow control to prevent fast lowering
  • Low Tension (24v) control box with up and down buttons
  • Lifetime lubricated bearings on lift arms
  • 1.7HP 115V motor with low amp draw and reliable performance
  • Runs on a standard 15 amp circuit
  • Category: Material Handling Equipment
  • Eligible for UPS: No
  • Final Weight: 550
  • Freight Class: 70
  • Hand Controls / Foot Controls: Hand Controls
  • Height Lowered: 8
  • LPI Part Number: 3G-4848
  • Lockstep Type: N/A
  • Motor HP: 1.7 HP
  • Overall Packaging Height: 15
  • Overall Packaging Length: 48
  • Overall Packaging Width: 48
  • Platform Height: 40
  • Platform Length: 48
  • Platform LxW: 48" x 48"
  • Platform Width: 48
  • Recommended Freight Method: LTL
  • Ship From Location: Waukesha
  • Shipping Dims. LxWxH: 48 x 48 x 15
  • Skid Dims: 48 x 48 x 7
  • Skid Height: 7
  • Skid Length: 48
  • Skid Width: 48
  • Sub: 4.00
  • Subcategory/Type: Lift Table
  • Tread: N/A
  • Weight Capacity: 3000
